Siemens 6ED1052-1FB00-0BA7 Replacement for LOGO! 8

Product Overview

Siemens 6ED1052-1FB00-0BA7 Replacement for LOGO! 8: Seamless Transition & Compatible Upgrade

The Siemens 6ED1052-1FB00-0BA7 is a compact logic module from the LOGO! 8 series, designed for 12/24V DC supply with relay output capability. As industrial facilities increasingly face the challenge of maintaining aging control infrastructure, sourcing a verified replacement or upgrade-compatible unit for the 6ED1052-1FB00-0BA7 has become a critical procurement priority. TOPNLMS supplies this module with full traceability, pre-shipment functional testing, and a 12-month warranty — enabling your engineering team to execute a smooth, low-risk migration from legacy LOGO! 0BA6 or earlier 0BA5 generations to the current LOGO! 8 platform.

Whether you are replacing a failed unit on an existing LOGO! 8 rack, upgrading from a discontinued LOGO! 6ED1052-1FB00-0BA6 (0BA6 generation), or consolidating multiple relay-output logic controllers into a single modernized architecture, the 6ED1052-1FB00-0BA7 offers backward-compatible I/O mapping, identical DIN-rail footprint, and full compatibility with LOGO! Soft Comfort V8 programming software. This means your existing ladder logic or FBD programs can be migrated with minimal rework, dramatically reducing commissioning time and unplanned downtime.

For facilities running mixed Siemens automation environments — including S7-1200 or S7-200 SMART PLCs alongside LOGO! modules — the 6ED1052-1FB00-0BA7 integrates cleanly via Modbus TCP or the onboard Ethernet port, allowing it to serve as a distributed I/O node or standalone controller within a broader SCADA or HMI architecture. Its compact 72mm housing fits standard control cabinet cutouts without panel modification, making it an ideal drop-in replacement in space-constrained enclosures.

Compatibility Comparison Table

Seamless Upgrade Solutions

A successful migration from a legacy LOGO! 0BA6 system to the 6ED1052-1FB00-0BA7 typically involves more than a single module swap. In practice, engineering teams also evaluate the surrounding control architecture to ensure full system compatibility and future scalability.

For installations requiring expanded I/O capacity, the LOGO! DM8 12/24R (6ED1055-1MB00-0BA2) digital expansion module connects directly to the base unit via the LOGO! Bus interface, adding 4 additional digital inputs and 4 relay outputs without requiring a separate power supply or communication configuration. Similarly, the LOGO! AM2 (6ED1055-1MA00-0BA2) analog expansion module supports 0–10V and 4–20mA signal acquisition, making it suitable for process control applications involving temperature, pressure, or flow transmitters.

For projects where the existing control cabinet also houses a LOGO! TD (6ED1055-4MH00-0BA2) text display or a LOGO! TDE (6ED1055-4MH08-0BA1) operator panel, both remain fully compatible with the 6ED1052-1FB00-0BA7 base unit. The TDE in particular supports Ethernet connectivity, enabling remote HMI access without additional hardware investment.

In larger retrofit projects where the LOGO! 8 module is integrated alongside a Siemens S7-1200 CPU 1214C (6ES7214-1AG40-0XB0) as a supervisory controller, Modbus TCP communication between the two platforms can be configured natively within TIA Portal and LOGO! Soft Comfort V8, eliminating the need for protocol converters or signal isolators in most standard applications.

Power supply compatibility is another key consideration. The Siemens LOGO! Power 24V/2.5A (6EP1332-1SH43) SITOP-class power supply is dimensioned to support the 6ED1052-1FB00-0BA7 base unit plus up to three expansion modules on a shared 24V DC rail, making it a reliable choice for consolidated control cabinet designs. For installations with strict signal isolation requirements between the PLC power rail and field devices, a Phoenix Contact MINI MCR signal isolator or equivalent DIN-rail isolator module is recommended between the analog input terminals and field transmitters.

Finally, for programming and firmware update tasks during commissioning, a standard Ethernet patch cable (Cat5e or Cat6) connected directly from the engineering laptop to the onboard RJ45 port of the 6ED1052-1FB00-0BA7 is sufficient — no dedicated programming cable or USB adapter is required, unlike earlier LOGO! generations that relied on the LOGO! PC cable (6ED1057-1AA01-0BA0).

Retrofit Guidance FAQ

Q: Can I reuse the existing wiring from my LOGO! 0BA6 installation?
A: Yes. The terminal layout and screw terminal pitch of the 6ED1052-1FB00-0BA7 are identical to the 0BA6 generation. Input and output wiring can be transferred directly without modification, provided the field device voltage levels remain within the 12/24V DC specification.

Q: Do I need to rewrite my control program?
A: No full rewrite is required. Programs created in LOGO! Soft Comfort V7 for the 0BA6 can be opened and converted in LOGO! Soft Comfort V8. Most standard function blocks — timers, counters, comparators, and relay logic — are directly compatible. Review any network communication blocks if your original program used LOGO! Bus peer-to-peer messaging, as the 0BA7 uses Ethernet-based communication for inter-device data exchange.

Q: Is the physical installation space the same?
A: Yes. The 6ED1052-1FB00-0BA7 occupies the same 72mm DIN-rail width as the 0BA6. No panel cutout modification or DIN-rail repositioning is required. The module snaps onto a standard 35mm DIN rail and is secured with the integrated locking tab.

Q: What communication protocols does the 6ED1052-1FB00-0BA7 support?
A: The module supports Modbus TCP (client and server), LOGO! Bus for expansion module communication, and a built-in web server accessible via standard browser over Ethernet. It does not natively support PROFIBUS DP or PROFINET without an additional gateway module.

Q: How do I handle the transition from LOGO! Bus peer-to-peer to Ethernet-based networking?
A: If your legacy system used LOGO! Bus for data exchange between multiple LOGO! units, the 0BA7 replaces this with Ethernet-based Modbus TCP connections. Each LOGO! 8 unit on the network requires a unique IP address. Configuration is performed in LOGO! Soft Comfort V8 under the network settings tab. A standard managed or unmanaged Ethernet switch is sufficient for multi-node installations.

Q: What is the recommended spare parts strategy for this module?
A: For critical applications, TOPNLMS recommends maintaining one spare 6ED1052-1FB00-0BA7 unit on-site. The module’s Micro SD card slot allows program backup and rapid restoration on a replacement unit without a laptop — insert the card, power on, and the program loads automatically.

Warranty Assurance

Every 6ED1052-1FB00-0BA7 unit supplied by TOPNLMS is covered by a 12-month warranty from the date of shipment. Prior to dispatch, each module undergoes a functional pre-shipment test including power-on verification, I/O channel continuity check, and communication port validation. Units are shipped in original or equivalent anti-static protective packaging with full documentation.

In the event of a confirmed hardware defect within the warranty period, TOPNLMS provides a replacement unit or full refund at the buyer’s discretion. Our after-sales response target is within 24 business hours of defect notification. Warranty claims require the original order reference and a brief description of the fault condition — no return merchandise authorization (RMA) bureaucracy.

For procurement teams managing multi-site rollouts or scheduled maintenance windows, TOPNLMS can hold allocated stock against a purchase order, ensuring unit availability aligns with your planned outage schedule. Bulk order pricing and lead-time commitments are available on request.

For technical pre-sales consultation, compatibility verification, or urgent replacement sourcing, contact our industrial automation team directly:

📧 [email protected] | 📞 +86 18359293191
