Kollmorgen AKM23D-ANBNC-00 Replacement for AKM Series

Product Overview

Kollmorgen AKM23D-ANBNC-00 Replacement for AKM Series: Smooth Transition & Legacy System Compatibility

The Kollmorgen AKM23D-ANBNC-00 is a Frame 23 brushless AC servo motor engineered for precision motion control in demanding industrial automation environments. As legacy servo systems age and OEM support for discontinued drive-motor combinations becomes increasingly scarce, facilities running older Kollmorgen S200, S300, Servostar 600, or AKD servo drive platforms face mounting pressure to source reliable, drop-in compatible replacements that preserve existing wiring infrastructure, encoder feedback loops, and drive tuning parameters — without triggering a full control cabinet redesign.

This unit — SKU AKM23D-ANBNC-00 — delivers a smooth migration path for engineers and maintenance teams upgrading from end-of-life servo configurations. With an IP65 ingress protection rating and a standard incremental encoder interface, it integrates directly into existing motion control architectures where the original AKM23 frame footprint, shaft dimensions, and connector pinout must be preserved. Whether your facility is retiring a Kollmorgen Servostar 600 drive system, decommissioning a legacy SERCOS-based motion network, or simply replacing a failed motor in a multi-axis gantry, conveyor, or pick-and-place application, the AKM23D-ANBNC-00 provides the mechanical and electrical compatibility needed to restore production with minimal downtime.

TOPNLMS maintains verified inventory of this SKU and ships from our Xiamen warehouse. Same-day dispatch is available for orders confirmed before 15:00 CST. Each unit is covered by a 12-month warranty and ships with a packing list, commercial invoice, and pre-shipment test record.

Compatibility Comparison Table

Seamless Upgrade Solutions

A successful AKM23D-ANBNC-00 retrofit rarely involves the motor alone. In most field installations, the servo motor operates within a broader motion control ecosystem that must be evaluated holistically before commissioning the replacement unit.

For facilities running the Kollmorgen AKD servo drive or the newer AKD2G dual-axis drive, the AKM23D-ANBNC-00 pairs directly using the standard AKM motor power cable and M23 feedback harness — no re-pinning required when the original cable assembly is intact. Engineers migrating from a Kollmorgen Servostar 600 or S300 drive should verify the motor model code mapping in WorkBench or S300 commissioning software to ensure the inertia, back-EMF constant, and thermal model parameters are updated to match this specific AKM23D variant before enabling the drive.

When the encoder feedback cable has degraded alongside the motor, the Kollmorgen CFB-AKM feedback cable (M23 to D-sub, shielded, twisted-pair) is the recommended replacement to maintain signal integrity over long cable runs in electrically noisy environments. Similarly, if the power cable connector shows wear or heat damage, the Kollmorgen CPB motor power cable for Frame 23 motors ensures correct phase sequencing and ground continuity without field-fabricated assemblies that introduce risk.

For multi-axis systems where the AKM23D-ANBNC-00 operates alongside larger frame motors — such as the AKM42 or AKM52 series — the shared DC bus architecture of the AKD platform means that bus capacitance and regenerative braking calculations should be revisited after any motor substitution. In applications where the original system used a Kollmorgen AKD-P00306 or AKD-P00606 drive, the drive’s auto-identification (motor ID) routine will recognize the AKM23D motor model and load the appropriate default parameters automatically, significantly reducing commissioning time.

Control cabinet integrators replacing this motor in a multi-axis gantry or packaging line should also audit the 24VDC brake supply circuit if the AKM23D variant includes an integrated holding brake, and confirm that the safety relay module or STO (Safe Torque Off) wiring to the drive remains compliant with the original machine safety category. Where EtherCAT topology is used, the AKD EtherCAT node address and axis mapping in the PLC program — typically a Beckhoff TwinCAT or Siemens S7-1500 controller — must be preserved to avoid axis reassignment errors on first power-up after the motor swap.

For facilities maintaining a buffer stock of critical motion components, pairing this AKM23D-ANBNC-00 unit with a spare AKM23 feedback connector kit and a set of motor terminal sealing plugs ensures that the next unplanned failure can be resolved within a single shift rather than waiting on international freight lead times. TOPNLMS supports standing purchase agreements and consignment stock arrangements for high-demand SKUs — contact our sales team to discuss priority allocation.

Retrofit Guidance FAQ

Q: Can I wire the AKM23D-ANBNC-00 directly to my existing Servostar 600 drive without rewiring the cabinet?
A: In most cases, yes. The AKM23D uses the standard Kollmorgen motor power and feedback connector pinout for Frame 23 motors. Verify the motor cable part number matches the Frame 23 specification. If the existing cable was manufactured for an earlier AKM23 revision, the pinout is typically identical — inspect the connector shell for mechanical compatibility before installation.

Q: Do I need to re-tune the drive after replacing the motor?
A: If replacing with the same AKM23D-ANBNC-00 model code, the drive’s stored motor parameters remain valid and no re-tuning is required. If migrating from a different AKM23 suffix (e.g., ANANA or ANBNB), run the auto-tuning routine in WorkBench or update the motor model in the drive’s parameter set to match the D-winding and N-feedback designations of this unit.

Q: Is the IP65 rating sufficient for washdown or outdoor enclosure applications?
A: IP65 provides full dust exclusion and protection against low-pressure water jets from any direction. It is suitable for food-grade washdown environments and outdoor enclosures with appropriate cable entry sealing. It is not rated for submersion (IP67/68) or high-pressure steam cleaning.

Q: What communication protocols does this motor support when paired with an AKD drive?
A: The AKM23D-ANBNC-00 is a passive motor — communication protocol is determined by the drive. The AKD platform supports EtherCAT, CANopen, PROFINET (via gateway), and analog ±10V command interfaces. The motor itself is protocol-agnostic and compatible with all AKD drive communication variants.

Q: Will this motor fit in the same physical space as the unit it replaces?
A: Frame 23 dimensions are standardized across the AKM23 series. The AKM23D-ANBNC-00 shares the same bolt circle, shaft diameter, and overall length envelope as other AKM23 variants, making it a direct mechanical replacement without cabinet modification in the vast majority of installations.

Q: What if my PLC program references the old motor’s encoder resolution?
A: Verify the encoder PPR (pulses per revolution) in your PLC axis configuration matches the encoder specification for this model. If the legacy motor used a different line count, update the axis scaling parameter in your motion controller — whether a Siemens S7, Beckhoff TwinCAT, or Rockwell Logix platform — to maintain accurate position feedback after the swap.

Warranty Assurance

Every Kollmorgen AKM23D-ANBNC-00 unit shipped by TOPNLMS is covered by a 12-month warranty from the date of delivery. Prior to dispatch, each unit undergoes functional verification including insulation resistance testing, encoder signal integrity check, and visual inspection of connector shells, shaft seal condition, and nameplate legibility.

If a unit exhibits a defect in materials or workmanship within the warranty period, TOPNLMS will arrange replacement or repair at no additional cost to the buyer. Our after-sales response target is within 24 business hours of a warranty claim submission. Replacement units are dispatched from our Xiamen warehouse, with express international freight options available to minimize production downtime for overseas customers.

For procurement teams requiring documentation, we provide a packing list, commercial invoice, and pre-shipment test record with each shipment. Bulk orders and standing purchase agreements for critical spare parts are supported — contact our sales team to discuss consignment stock arrangements or priority allocation for high-demand SKUs.

TOPNLMS maintains inventory of Kollmorgen AKM series motors, AKD drives, and associated motion control components to support both emergency replacement orders and planned maintenance programs. Same-day dispatch is available for in-stock units on orders confirmed before 15:00 CST.
