Hydac EDS1791-N-016-000 Replacement for EDS 1791 Series

Product Overview

Hydac EDS1791-N-016-000 Replacement for EDS 1791 Series: Seamless Transition & Compatible Upgrade

When your hydraulic or pneumatic control system relies on the Hydac EDS1791-N-016-000 electronic pressure switch and the original unit reaches end-of-life or becomes unavailable, a smooth, validated replacement is critical to maintaining system uptime. The EDS1791-N-016-000 belongs to Hydac’s proven EDS 1791 Series — a compact, robust electronic pressure switch widely deployed in industrial hydraulic power units, mobile machinery, injection molding machines, and process automation systems. This replacement solution is engineered to deliver a drop-in upgrade path with full compatibility across wiring, signal output, pressure range, and installation footprint.

The EDS1791-N-016-000 features a 0–16 bar measuring range, a 4-pin M12 connector interface, and dual switching outputs with an analog signal output (4–20 mA or 0–10 V depending on configuration). These specifications make it directly interchangeable with legacy EDS 1791 variants and compatible with a wide range of PLCs, DCS controllers, and I/O modules from Siemens, Beckhoff, Allen-Bradley, and Schneider Electric. Whether your existing system uses a Siemens S7-300 analog input module, a Beckhoff EL3102 differential input terminal, or a Schneider Electric Modicon M340 analog I/O card, the EDS1791-N-016-000’s standard signal output integrates without rewiring or signal conditioning.

In retrofit projects, engineers frequently encounter the challenge of replacing aging pressure sensing components while keeping the surrounding control architecture intact. The EDS1791-N-016-000 retains the same G1/4 process connection thread and M12 connector pinout as earlier EDS 1791 models, eliminating the need to modify hydraulic manifold ports or reroute signal cables. This is particularly valuable in compact control cabinets where space constraints make rewiring costly and time-consuming. The unit’s stainless steel wetted parts and IP67 protection rating ensure continued reliability in harsh environments, including those with hydraulic oil, coolant, or high-humidity exposure.

For systems previously using the Hydac EDS 3000 Series or EDS 4000 Series pressure switches, the EDS1791-N-016-000 serves as a cost-effective downgrade-compatible replacement where the higher-end diagnostics of the EDS 4000 are not required. In such migrations, the analog output wiring to the PLC’s analog input card remains unchanged, and only the switching threshold parameters need to be reconfigured via the unit’s push-button interface — no programming cable or software tool is required. This significantly reduces commissioning time during planned maintenance windows or emergency replacements.

When integrating the EDS1791-N-016-000 into a modernized control system, it is common to pair it with a Hydac HDA 4000 Series pressure transmitter for redundant pressure monitoring on critical circuits, or with a Hydac ETS 1700 Series temperature switch for combined pressure-temperature interlock logic. In mobile hydraulic applications, the EDS1791-N-016-000 is frequently installed alongside Hydac HST Series hydraulic accumulators and monitored via a Hydac HMG 3010 mobile data recorder for field diagnostics. For systems requiring IO-Link communication, the Hydac EDS 4000 IO-Link variant is the recommended upgrade path, while the EDS1791-N-016-000 remains the preferred choice for standard analog and switching output architectures.

In stationary industrial applications — such as hydraulic press systems, die-casting machines, or CNC machining centers — the EDS1791-N-016-000 is typically wired to a Siemens ET 200SP analog input module or a Phoenix Contact MINI Analog signal conditioner to interface with the plant’s PROFIBUS or PROFINET network. The switch’s PNP/NPN configurable outputs are compatible with both sourcing and sinking input cards, making it universally adaptable across control platforms without additional relay or signal converter modules.

Procurement teams benefit from knowing that this replacement unit is sourced from verified supply channels, individually tested for pressure accuracy and switching repeatability before shipment, and backed by a 12-month warranty. Stock is maintained in Xiamen for rapid dispatch, with DHL Express and FedEx International Priority available for urgent orders. Lead time for in-stock units is typically 1–3 business days from order confirmation.

Compatibility Comparison Table

Seamless Upgrade Solutions

A successful EDS1791-N-016-000 retrofit rarely involves the pressure switch in isolation. In most hydraulic control systems, the pressure switch works in concert with a broader sensor and control architecture. During the upgrade process, engineers commonly evaluate the condition of adjacent components to avoid repeat maintenance calls. The Hydac HDA 4745 pressure transmitter is frequently replaced alongside the EDS1791-N-016-000 in hydraulic power unit overhauls, providing continuous 4–20 mA pressure feedback to the PLC while the EDS1791 handles discrete switching logic. Similarly, the Hydac ETS 1701 temperature switch is often co-located in the same hydraulic manifold block and benefits from simultaneous replacement to standardize the maintenance cycle.

For control cabinet integration, the analog signal from the EDS1791-N-016-000 is typically routed through a Phoenix Contact MCR-SL-S signal isolator or a Weidmüller ACT20P signal conditioner before reaching the PLC’s analog input card — particularly in older installations where ground loop isolation is required. In newer Siemens TIA Portal-based systems, the signal connects directly to a Siemens SM 331 analog input module or an ET 200SP AI 4×U/I 2-wire HF module without additional conditioning. For Beckhoff-based systems, the Beckhoff EL3054 4-channel 4–20 mA input terminal provides a direct, noise-immune interface for the EDS1791’s analog output.

In mobile hydraulic applications, the EDS1791-N-016-000 is commonly paired with a Hydac FCU 1000 Series filter condition unit and a Hydac VS Series flow switch to provide comprehensive fluid condition monitoring. The switching outputs of the EDS1791 can be wired directly to a Hydac HMG 3010 handheld data recorder for on-site commissioning and threshold verification without requiring a laptop or programming software. This makes field replacement and re-commissioning straightforward even in remote or mobile equipment environments.

Retrofit Guidance FAQ

Q: Can I replace the EDS1791-N-016-000 without modifying the hydraulic manifold?
A: Yes. The EDS1791-N-016-000 uses a standard G1/4 male process connection, which is identical to all EDS 1791 Series variants. No manifold modification, adapter fitting, or sealant change is required. Simply drain the circuit, unscrew the old unit, and thread in the replacement.

Q: Will the existing M12 cable and wiring harness work with the replacement unit?
A: Yes. The EDS1791-N-016-000 uses the same 4-pin M12 × 1 connector with an identical pinout (Pin 1: supply +, Pin 3: supply −, Pin 2: switching output 1, Pin 4: switching output 2 / analog output). No rewiring or new cable assembly is needed.

Q: Do I need to reconfigure the PLC program after replacement?
A: No program changes are required if the replacement unit is configured to the same switching thresholds as the original. The EDS1791-N-016-000 switching points are set via the front-panel push buttons and are retained in non-volatile memory. The PLC sees the same signal behavior as before.

Q: Is the EDS1791-N-016-000 compatible with PROFIBUS or PROFINET systems?
A: The EDS1791-N-016-000 itself communicates via analog signal (4–20 mA or 0–10 V) and discrete switching outputs — not via fieldbus. It connects to the PLC’s analog input module, which then communicates over PROFIBUS or PROFINET. No fieldbus configuration changes are needed at the network level.

Q: What is the physical installation space requirement?
A: The EDS1791-N-016-000 has a compact cylindrical housing with a hex wrench flat for G1/4 installation. The overall installed length (including M12 connector) is approximately 75 mm. It fits in the same installation envelope as the original EDS 1791 unit with no control cabinet or panel modifications required.

Q: Can this unit replace EDS 3000 or EDS 4000 Series switches in a downgrade scenario?
A: In applications where the advanced diagnostics and IO-Link communication of the EDS 4000 are not utilized, the EDS1791-N-016-000 can serve as a cost-effective functional replacement. Verify that the analog output range and switching output configuration match the PLC input card specifications before installation.

Warranty Assurance

Every EDS1791-N-016-000 unit supplied by TOPNLMS is covered by a 12-month warranty from the date of shipment. Prior to dispatch, each unit undergoes individual functional testing including pressure accuracy verification, switching point repeatability check, analog output linearity test, and IP67 seal integrity inspection. Test records are available upon request for quality-critical procurement processes.

In the event of a warranty claim, TOPNLMS provides a replacement unit or full refund within the warranty period. Our after-sales response time is within 24 hours for all warranty inquiries. Replacement units are dispatched from Xiamen stock with priority shipping to minimize your system downtime. We support EXW, FOB Xiamen, and CIF destination Incoterms for international orders, with full export documentation including commercial invoice, packing list, and certificate of origin available for customs clearance.

For urgent replacement requirements, same-day dispatch is available for in-stock units when orders are confirmed before 14:00 CST. DHL Express, FedEx International Priority, and UPS Worldwide Express are available as shipping options. Bulk procurement pricing and consignment stock arrangements are available for OEM customers and MRO distributors with recurring demand for EDS 1791 Series components.

Contact our technical sales team for pre-purchase compatibility confirmation, cross-reference verification, or application-specific configuration advice before placing your order.
