Product Overview

HORIBA SEC-Z719MGX Replacement for SU8000 Series: Seamless Transition from Legacy MFC Systems

The HORIBA SEC-Z719MGX (full part number: SEC-Z719MGX SUR11HGBFRKG/W/US-100-IPF, SU8000 series) is a high-precision digital mass flow controller rated at 100 sccm for HBr (Hydrogen Bromide) gas service. Designed for semiconductor etch and CVD process chambers, this unit is a direct replacement for aging or discontinued SU-series MFC models deployed across 200mm and 300mm fab environments. Whether your facility is retiring end-of-life SEC-Z500 or SEC-Z700 series controllers, or migrating from analog signal-based flow control to digital RS-485 / DeviceNet communication architectures, the SEC-Z719MGX provides a validated, drop-in upgrade path with minimal process re-qualification.

Procurement teams and process engineers managing legacy tool fleets — including Lam Research, Applied Materials, and TEL etch chambers — frequently source the SEC-Z719MGX as a like-for-like replacement when OEM support for older HORIBA SEC-Z series units has been discontinued. The SU8000 platform’s digital communication interface, combined with its corrosion-resistant wetted materials optimized for halogen gas service (HBr, Cl₂, NF₃), makes it a preferred choice for both emergency replacement and planned preventive maintenance programs.

TOPNLMS maintains verified stock of the SEC-Z719MGX SUR11HGBFRKG/W/US-100-IPF, sourced from authorized distribution channels, with full pre-shipment functional testing and a 12-month warranty. Units ship from Xiamen, China, with DHL Express and FedEx International Priority options available for urgent fab downtime recovery.

Compatibility Comparison Table

Seamless Upgrade Solutions

A successful SEC-Z719MGX installation in a legacy etch tool typically involves more than a single component swap. Process engineers migrating from analog MFC infrastructure to the SU8000 digital platform often need to address the broader gas delivery and control architecture simultaneously. The SEC-Z719MGX integrates directly with HORIBA’s SEC-Z series manifold blocks and VCR-face-seal gas stick assemblies, eliminating the need for new gas panel fabrication in most retrofit scenarios.

For facilities upgrading multiple flow channels in a single tool, the HORIBA SEC-Z710MGX (10 sccm) and SEC-Z750MGX (500 sccm) are commonly ordered alongside the SEC-Z719MGX to complete a full gas box refresh. The SU8000 platform’s digital communication backbone is typically managed through a HORIBA SEC-8000 MFC controller or a compatible third-party MFC driver card installed in the tool’s process module controller (PMC) rack.

When migrating from analog signal wiring, a signal conversion interface module — such as the HORIBA D/A converter accessory or an equivalent 0–5V to RS-485 bridge — is required to maintain compatibility with existing PLC I/O cards or tool host software. Facilities running Brooks Instrument or MKS Instruments legacy MFCs in adjacent process steps may also consider cross-platform signal normalization at the MFC junction box level to simplify the tool’s overall I/O map.

Additional components commonly sourced during a gas delivery system retrofit include VCR gaskets (316L SS or Ni, 1/4″ and 1/8″ sizes), high-purity pneumatic shut-off valves for upstream isolation, and corrosion-resistant pressure transducers rated for HBr service. For tools requiring re-qualification after MFC replacement, a portable MFC calibration reference standard traceable to NIST is recommended to verify the SEC-Z719MGX’s flow accuracy at the installed operating point before returning the chamber to production.

Facilities managing a broader DCS or PLC-based gas control architecture — for example, Siemens S7-300 or Allen-Bradley ControlLogix platforms interfacing with the fab’s gas management system — should verify that the RS-485 node address and baud rate settings on the SEC-Z719MGX are configured to match the existing network topology before commissioning. TOPNLMS can provide pre-configuration support and factory test data sheets upon request.

Retrofit Guidance FAQ

Q: Is the SEC-Z719MGX a direct pin-compatible replacement for my existing analog HORIBA MFC?
A: The SEC-Z719MGX uses a 24 VDC digital interface (RS-485 / DeviceNet) rather than the ±15 VDC analog signal standard on older SEC-Z500/Z700 units. The mechanical footprint, VCR fittings, and gas wetted path are identical, so no plumbing changes are required. However, the electrical connector and signal protocol differ — a wiring adapter or signal conversion module is needed if your tool host still uses analog MFC driver cards.

Q: Can I use the SEC-Z719MGX with my existing PROFIBUS or DeviceNet gas control network?
A: Yes. The SU8000 series supports RS-485 as standard, with optional DeviceNet and PROFIBUS fieldbus modules available. Confirm the communication option code in the full part number (SUR11HGBFRKG/W/US-100-IPF) with TOPNLMS before ordering if your network requires a specific fieldbus variant.

Q: What is the physical installation space requirement?
A: The SEC-Z719MGX conforms to the SEMI standard MFC form factor. It is a direct mechanical replacement for all HORIBA SEC-Z series units and most third-party MFCs using the same 1/4″ VCR face-seal gas stick standard. No bracket modification or gas panel re-machining is required in standard installations.

Q: How do I verify flow accuracy after installation?
A: TOPNLMS ships each SEC-Z719MGX with a factory calibration certificate. For in-situ verification, use a portable primary flow standard (e.g., a Bios DryCal or equivalent) at the tool’s process conditions. The SU8000 digital interface also supports real-time flow diagnostics via the RS-485 command set, allowing engineers to read valve position, sensor temperature, and flow deviation without removing the unit from the gas line.

Q: What if my replacement unit fails within the warranty period?
A: TOPNLMS provides a 12-month warranty covering manufacturing defects and functional failures under normal operating conditions. Failed units are replaced or repaired at no charge. Our technical team responds to warranty claims within 24 hours, and replacement units are dispatched within 3 business days for urgent fab recovery situations.

Warranty Assurance

Every HORIBA SEC-Z719MGX SUR11HGBFRKG/W/US-100-IPF unit shipped by TOPNLMS is covered by a 12-month warranty from the date of delivery. Prior to shipment, each unit undergoes a multi-point functional inspection including leak integrity check, valve actuation test, flow sensor response verification, and communication interface handshake confirmation. A factory test data sheet is available upon request.

Our warranty covers all manufacturing defects and functional failures arising under normal semiconductor process conditions. In the event of a warranty claim, TOPNLMS commits to a 24-hour response, with replacement units dispatched within 3 business days to minimize tool downtime. For critical fab recovery situations, expedited air freight options are available at cost.

Procurement teams can request a Certificate of Conformance (CoC), material traceability documentation, and MSDS/SDS for HBr-rated wetted materials as part of the standard order package. Volume pricing and consignment stock arrangements are available for facilities managing ongoing MFC lifecycle programs.

To place an order or request a quotation, contact TOPNLMS directly:

• Email: [email protected]
• Phone / WhatsApp: +86 18359293191
• Website: https://topnlms.com
