GE UR-RHH Original Spare Power Supply UR Series

Product Overview

GE UR-RHH Original Spare Power Supply UR Series: System Stability Through Reliable Industrial Maintenance

The GE UR-RHH is the dedicated chassis power supply module for the GE Universal Relay (UR) Series protection relay platform — one of the most widely deployed digital protection and control systems in transmission substations, generation facilities, and industrial power distribution networks worldwide. As a direct original spare, the UR-RHH delivers regulated DC power to the UR relay chassis backplane, sustaining the continuous operation of all installed function modules and ensuring the protection system remains fully energized and operationally ready at all times.

In any substation or industrial power facility, the power supply module is the single most critical component in the relay chassis. A degraded or failed UR-RHH does not merely affect one function — it takes the entire protection relay offline, exposing the system to unprotected fault conditions and potential equipment damage. Maintaining a verified, tested spare UR-RHH in your site inventory is not optional for facilities operating GE UR Series relays; it is a fundamental element of responsible asset management and grid reliability strategy.

Critical Technical Specs Table

Preventive Maintenance Strategy

Experienced protection engineers understand that a power supply failure in a UR Series chassis is rarely an isolated event. Thermal stress, input voltage transients, and aging capacitors affect the UR-RHH over time, and when a PSU begins to degrade, the downstream effects on co-installed modules can be significant. A structured preventive maintenance approach for GE UR Series installations should treat the UR-RHH as part of a broader chassis health review.

During any scheduled outage or relay inspection, the UR-RHH should be evaluated alongside the GE UR-8xx CPU/DSP module, which processes all protection algorithms and is directly dependent on stable backplane power. Voltage ripple or dropout events from a weakening PSU can cause the CPU module to log spurious events or, in severe cases, initiate unintended relay operations. Similarly, the GE UR analog input modules (such as the UR-4CT or UR-4VT) are sensitive to power quality on the backplane — any instability from the UR-RHH will manifest as measurement drift or calibration errors in current and voltage sensing channels.

The GE UR digital I/O modules (including the UR-8D series) rely on the chassis PSU for both logic power and output relay coil energization. A marginal UR-RHH may cause intermittent output contact operation, which is particularly dangerous in trip and close circuits connected to circuit breakers. Maintenance teams should verify output relay operation on all I/O modules whenever a PSU replacement is performed.

Communications continuity is equally important. The GE UR communications module (supporting IEC 61850 GOOSE, DNP3, or Modbus protocols depending on the installed card) draws power from the same chassis backplane. After replacing the UR-RHH, engineers should verify that all communication links — including fiber-optic connections to the station LAN and serial links to RTUs — re-establish correctly and that no IEC 61850 dataset subscriptions have been lost.

For sites using the GE UR-RxH rear terminal assembly, the physical wiring interface to the chassis remains in place during a PSU swap, which significantly reduces replacement time and eliminates the risk of wiring errors. Facilities that have not yet standardized on the UR rear terminal assembly should consider doing so as part of their next maintenance cycle to simplify future module replacements.

A complete chassis maintenance kit for GE UR Series installations should also include a spare GE UR-RxA or UR-RxB power supply variant appropriate for the site’s nominal input voltage, a GE UR programming cable (typically USB-to-RS232 or USB-to-RJ45 depending on relay generation) for post-replacement settings verification, and a copy of the relay’s settings file backed up from the GE EnerVista UR Setup software. Settings verification after any module replacement is mandatory — the UR platform performs automatic self-checks on startup, but a manual settings audit ensures that all protection elements, CT/VT ratios, and communication parameters remain intact.

For facilities managing multiple UR Series relays across a substation — such as a combination of GE C60 line protection relays, GE F60 feeder protection relays, and GE T60 transformer protection relays — a centralized spare parts strategy that includes at least one UR-RHH per chassis type is strongly recommended. The UR-RHH is common across most UR platform chassis variants, making it an efficient single-SKU spare that covers a broad range of installed assets.

Strategic Replacement Solutions

The GE UR-RHH is a direct plug-in replacement for the original factory-installed power supply in any compatible UR Series chassis. No firmware changes, no settings modifications, and no reconfiguration of protection elements are required following a like-for-like PSU replacement. The module is keyed to the chassis slot and cannot be installed incorrectly, which minimizes the risk of human error during emergency replacements under time pressure.

For facilities transitioning from older GE Multilin relay platforms — such as the GE SR series or early-generation UR relays — to current UR platform hardware, the UR-RHH power supply architecture represents a significant improvement in input voltage range and thermal management. The wide-range AC/DC input (85–300 V) eliminates the need for separate PSU variants for AC-supplied and DC-supplied panels, simplifying spare parts inventory and reducing procurement complexity.

TOPNLMS maintains stock of the UR-RHH specifically to support emergency replacement scenarios where substation downtime must be minimized. All units are tested prior to shipment, packaged in ESD-safe materials, and accompanied by a test report. Worldwide shipping is available with express options for critical infrastructure customers. Our 12-month warranty covers all manufacturing defects and functional failures under normal operating conditions, with direct technical support available for installation and commissioning questions.

Support FAQ

Q1: How do I verify that the UR-RHH is the correct power supply for my relay chassis?
The UR-RHH is identified by the module label on the front panel and the chassis slot designation. Cross-reference the relay model number (e.g., C60, F60, T60) with the GE UR Series hardware manual to confirm PSU compatibility. TOPNLMS technical support can assist with compatibility verification if you provide the relay model and firmware version.

Q2: Can the UR-RHH be replaced while the relay is in service?
Hot-swap capability depends on whether the chassis is equipped with a redundant PSU slot. Single-PSU chassis configurations require a planned outage for safe replacement. Always follow your site’s protection relay maintenance procedures and coordinate with the system operator before removing any energized protection relay from service.

Q3: What testing is performed on UR-RHH units before shipment?
Each UR-RHH unit supplied by TOPNLMS undergoes functional power-on testing, output voltage verification, and visual inspection for physical damage. A test report is included with each shipment. Units are packaged in anti-static bags with foam protection to prevent transit damage.

Q4: What does the 12-month warranty cover?
The TOPNLMS 12-month warranty covers all manufacturing defects and functional failures under normal operating conditions from the date of shipment. Warranty claims are processed with priority response — contact [email protected] with your order number and a description of the fault. Replacement or repair is arranged at no additional cost within the warranty period.
