Four Star Electronics SC-20 RS232/TTY Replacement Solution

Product Overview

Four Star Electronics SC-20 RS232/TTY Replacement Solution: Seamless Legacy Serial Interface Upgrade

The Four Star Electronics SC-20 is a dedicated RS232 to TTY 20mA current loop converter designed for industrial serial communication applications in legacy PLC, DCS, and process control systems. As original SC-20 units reach end-of-life or become increasingly difficult to source, plant engineers and system integrators face the challenge of maintaining reliable serial communication links between host controllers and field devices without triggering a full system overhaul. This replacement solution is engineered to deliver a drop-in upgrade path that preserves your existing wiring infrastructure, communication protocols, and control cabinet layout while eliminating the risks associated with obsolete hardware.

The SC-20 converts standard RS232 signals to a 20mA TTY (current loop) interface — a communication standard widely used in older Siemens S5 PLCs, Allen-Bradley PLC-2 and PLC-3 series controllers, Modicon 984 DCS platforms, and early SCADA terminal units. The 20mA current loop protocol offers inherent noise immunity over long cable runs, making it a preferred choice in electrically noisy industrial environments such as steel mills, chemical plants, and power generation facilities. Replacing a failed or aging SC-20 with a verified compatible unit ensures that your RS232-equipped host — whether a programming terminal, HMI, or supervisory computer — continues to communicate reliably with TTY-based field controllers and peripherals.

Compatibility Comparison Table

Seamless Upgrade Solutions

A successful SC-20 replacement rarely happens in isolation. In most legacy serial communication retrofits, the SC-20 sits at the boundary between an RS232 host port — typically on a Siemens S5-115U or S5-135U CPU module — and a 20mA current loop network serving remote I/O racks, operator terminals, or field-mounted controllers. During the replacement process, engineers frequently audit adjacent components to ensure the entire communication chain remains reliable.

On the RS232 host side, the programming port or communication port of the PLC CPU — such as the Siemens 6ES5 095-8MA02 CPU or the 6ES5 316-8MA12 — connects to the SC-20 via a standard DB9 or DB25 serial cable. If the CPU module itself is also aging, this is an ideal time to evaluate a coordinated replacement of both the CPU and the serial interface converter to eliminate two single points of failure simultaneously. Similarly, the Siemens 6ES5 700-8MA11 power supply module should be inspected, as unstable DC supply voltage is a common root cause of intermittent serial communication errors that are often misdiagnosed as converter failures.

On the TTY current loop side, the 20mA loop typically feeds into a remote I/O station or a dedicated communication interface module. In Siemens S5 architectures, this often involves the 6ES5 318-8MA12 interface module or a 6ES5 374-1AH21 memory module that stores the communication configuration. Replacing the SC-20 without verifying the integrity of the loop wiring and the termination resistors at the remote end can result in persistent communication faults even after the converter is swapped. A loop current meter or a dedicated serial analyzer should be used to validate the 20mA signal level before and after installation.

In control cabinets where space is constrained, the SC-20’s compact DIN rail form factor is a significant advantage. However, if the retrofit also involves upgrading from an S5 to a Siemens S7-300 platform — using a CPU 315-2 DP (6ES7 315-2AH14-0AB0) for example — the communication architecture changes fundamentally. The S7-300 uses PROFIBUS DP or MPI rather than TTY current loop, which means the SC-20 would be retired in favor of a CP 342-5 PROFIBUS communication processor or an ET 200M distributed I/O station. In such migration scenarios, the SC-20 serves as a bridging solution during the transition period, maintaining legacy device connectivity while the new S7 infrastructure is commissioned in parallel.

For Allen-Bradley PLC-2 or PLC-3 environments, the SC-20 typically interfaces with the 1771-KA2 communication adapter or the serial port of a 1785-L40B PLC-5 processor. When migrating these systems to a ControlLogix 1756-L71 platform, the TTY current loop devices must either be replaced with EtherNet/IP-compatible equivalents or bridged through a protocol converter. During the interim period, maintaining a working SC-20 in the legacy rack ensures that existing SCADA polling and data logging functions continue uninterrupted.

Retrofit Guidance FAQ

Q: Can I replace the SC-20 without modifying existing wiring?
A: Yes. The replacement SC-20 unit maintains the same RS232 DB9/DB25 connector pinout on the host side and the same screw-terminal TTY current loop connections on the field side. No wiring changes are required for a direct swap. Verify the loop polarity (active vs. passive) configuration matches your original unit before powering up.

Q: What baud rates and communication parameters are supported?
A: The SC-20 supports standard baud rates from 300 bps to 19,200 bps, with configurable data bits (7 or 8), parity (none, odd, even), and stop bits (1 or 2). These parameters are typically set via DIP switches on the unit and must match the configuration of the connected PLC or host device.

Q: Is optical isolation maintained in the replacement unit?
A: Yes. The replacement SC-20 incorporates optical isolation between the RS232 and TTY sides, providing the same ground loop protection and noise immunity as the original unit. This is critical in industrial environments where ground potential differences between the host computer and field devices can cause communication errors or equipment damage.

Q: How do I verify the 20mA current loop is functioning correctly after replacement?
A: Use a calibrated loop current meter in series with the TTY loop to confirm 20mA flow during the mark (logic 1) state. The loop should show approximately 0mA during the space (logic 0) state for active current loop configurations. If the loop current is incorrect, check the power supply voltage, loop resistance, and the active/passive configuration jumpers on both the SC-20 and the connected device.

Q: Can the SC-20 be used in a passive current loop configuration?
A: Yes. The SC-20 supports both active (self-powered) and passive (externally powered) current loop configurations. In passive mode, the loop current is supplied by the connected device or an external loop power supply. Ensure the total loop resistance is within the specified range for reliable 20mA operation.

Q: What is the physical installation space requirement?
A: The SC-20 mounts on standard 35mm DIN rail and requires approximately 45mm of rail space. Panel mounting is also supported via the integrated mounting flanges. The unit’s compact footprint makes it suitable for installation in existing control cabinets without requiring additional space allocation.

Warranty Assurance

Every SC-20 replacement unit shipped by TOPNLMS is covered by a 12-month warranty from the date of delivery. Prior to shipment, each unit undergoes functional testing that includes RS232 signal integrity verification, 20mA current loop output measurement, optical isolation continuity check, and baud rate configuration validation across the full supported range. This pre-shipment testing protocol ensures that the unit arrives ready for immediate installation, minimizing the time your system remains offline.

In the event of a warranty claim, TOPNLMS provides a straightforward replacement process: contact our technical support team with your order number and a description of the fault, and a replacement unit will be dispatched within 2 business days. We maintain dedicated stock of SC-20 replacement units to ensure rapid response to warranty claims and emergency procurement requests. Our technical team is available to assist with installation questions, configuration guidance, and compatibility verification for your specific application.

For urgent replacement requirements — such as unplanned downtime situations where production continuity depends on restoring serial communication — TOPNLMS offers expedited shipping from our Xiamen warehouse to destinations across mainland China, Hong Kong, Southeast Asia, and international markets. Standard lead time for in-stock units is 1–3 business days domestically and 5–10 business days for international shipments, subject to customs clearance.

Our procurement guarantee includes: verified unit functionality before shipment, secure anti-static packaging, full documentation (datasheet and configuration guide), and post-sale technical support for the duration of the warranty period. We understand that industrial control system downtime carries significant operational and financial consequences, and our fulfillment process is designed to minimize the time between your order and successful system restoration.
