CONVUM CVX-1243-MC2 OZ23 Replacement for CVX Series: Seamless Transition & Legacy System Compatibility

When your production line depends on a CONVUM CVX-1243-MC2 OZ23 multi-stage vacuum generator and the original unit reaches end-of-life, unplanned downtime is not an option. This replacement and upgrade solution is engineered specifically for facilities running legacy CVX Series vacuum systems, offering a smooth, drop-in migration path that preserves your existing wiring infrastructure, pneumatic circuit layout, and control logic without requiring a full system redesign.

The CVX-1243-MC2 OZ23 is a multi-stage vacuum generator from CONVUM’s CVX Series, widely deployed in semiconductor handling, SMT pick-and-place lines, robotic end-of-arm tooling, and precision assembly automation. As original units age or become discontinued, sourcing a verified replacement with confirmed dimensional, port, and performance compatibility becomes critical. Our replacement unit matches the original CVX-1243-MC2 OZ23 in vacuum level, flow rate, supply pressure range, and body dimensions, ensuring that your existing vacuum circuit — including suction cups, vacuum switches, and filter elements — continues to operate within specification.

For facilities integrating this vacuum generator into a broader automation architecture, the CVX-1243-MC2 OZ23 typically operates alongside a PLC-controlled solenoid valve manifold. In many CVX Series installations, the vacuum generator is governed by a Mitsubishi MELSEC Q-series or iQ-R series PLC output module driving a 24 VDC solenoid valve, such as those in the SMC SY series or CKD 4F series. The replacement unit maintains the same 24 VDC pilot signal compatibility, so no changes to the PLC output card wiring or ladder logic are required. If your system uses a Keyence CV-X series vision controller or an Omron NX/NJ series machine automation controller to trigger vacuum on/off sequences, the signal interface remains unchanged.

In retrofit scenarios where the original CVX-1243-MC2 OZ23 is mounted on a manifold block or integrated into a vacuum circuit with a CONVUM VPH series vacuum pressure switch or a CONVUM VQP series vacuum filter, the replacement unit is dimensionally compatible with standard CVX Series port spacing and thread specifications. This means your existing manifold, tubing, and filter assembly can be reused without modification, significantly reducing retrofit labor time and the risk of introducing new leak points.

For systems where the vacuum generator feeds into a centralized I/O monitoring architecture — for example, a Beckhoff EtherCAT I/O terminal block reading vacuum switch feedback signals, or a Siemens ET 200SP distributed I/O station collecting process status — the replacement CVX-1243-MC2 OZ23 produces the same analog and digital feedback characteristics as the original, ensuring your SCADA or HMI display (such as a Proface GP4000 series or Weintek cMT series panel) continues to reflect accurate vacuum status without recalibration.

Installation is straightforward: disconnect the supply air line (typically 0.4–0.5 MPa filtered dry air), remove the original unit from its mounting bracket or manifold, install the replacement using the existing port fittings and mounting hardware, reconnect the solenoid valve pilot line and vacuum switch signal cable, and restore supply pressure. A brief functional test — cycling the solenoid valve through the PLC and verifying vacuum level on the pressure switch — is all that is required before returning the line to production. Total installation time in a well-documented facility is typically under 30 minutes.

For facilities managing spare parts inventory across multiple production lines, we recommend stocking one replacement CVX-1243-MC2 OZ23 unit per line as a critical spare. Our warehouse maintains ready stock with same-day dispatch available for orders confirmed before 15:00 CST, with DHL Express and FedEx International Priority options for urgent international shipments from Xiamen.
