B&R 5PC810.SX05-00 Replacement for Automation PC 810

Product Overview

B&R 5PC810.SX05-00 Replacement for Automation PC 810: Seamless Migration from Legacy Systems

The B&R 5PC810.SX05-00 is a high-performance industrial panel PC from the Automation PC 810 series, engineered for demanding process control, machine automation, and SCADA visualization environments. As legacy B&R Automation PC 620 and Automation PC 810 installations approach end-of-life, plant engineers and procurement teams are actively seeking a verified, drop-in replacement that preserves existing wiring infrastructure, communication protocols, and control cabinet footprint — without triggering a full system redesign.

TOPNLMS supplies the 5PC810.SX05-00 as a direct replacement unit, fully tested and ready for field installation. Whether you are migrating from an older 5PC600.SX01-00 or 5PC600.SX02-00 Automation PC 600 platform, or retiring a worn 5PC810.SX02-00 within the same 810 family, this unit delivers a compatible upgrade path with minimal engineering overhead.

Compatibility Comparison Table

Seamless Upgrade Solutions

A successful migration from a legacy B&R Automation PC platform to the 5PC810.SX05-00 rarely involves the panel PC alone. In practice, field engineers encounter a chain of interdependent components that must be evaluated and, where necessary, upgraded in parallel to ensure system integrity.

The most common starting point is the X20 I/O system. Existing X20CP1485 or X20CP3485 CPU modules connected to the legacy panel PC via the X2X Link bus typically remain fully compatible with the 5PC810.SX05-00, provided the Automation Studio project is migrated to version 4.x. In cases where the existing X20PS9400 or X20PS9402 power supply modules are aging alongside the panel PC, it is advisable to replace them simultaneously to avoid a secondary unplanned outage.

Communication continuity is a critical concern during any panel PC swap. If the existing system relies on a 5ACPCI.ICAN-00 CAN interface card or a 5ACPCI.FPLS-00 POWERLINK interface card installed in the legacy PC’s PCI slot, these cards must be verified for physical slot compatibility with the 5PC810.SX05-00 chassis before installation. In many retrofit projects, engineers opt to migrate fieldbus communication to the onboard Gigabit Ethernet port using Modbus TCP or EtherNet/IP, eliminating the dependency on legacy PCI interface cards entirely.

For installations where the legacy panel PC was paired with a 5AP920.1505-01 or 5AP920.1906-01 Automation Panel display connected via SDL (Smart Display Link), the 5PC810.SX05-00’s onboard SDL interface ensures a direct, cable-compatible connection — no display replacement required. This is a significant advantage in control cabinet retrofits where panel cutout dimensions are fixed and display replacement would require mechanical rework.

Wiring to field devices — including terminal blocks, signal cables, and grounding conductors — is typically unaffected by the panel PC swap. However, if the existing installation uses a X20BB80 or X20BB27 bus base for I/O module mounting, engineers should confirm that the backplane firmware is current before commissioning the new panel PC to avoid communication initialization errors during startup.

In drive-integrated control architectures, where the legacy panel PC coordinated motion sequences with ACOPOS or ACOPOSmulti servo drives via POWERLINK, the 5PC810.SX05-00 maintains full POWERLINK cycle-time compatibility, preserving existing motion program logic without requiring drive parameter re-tuning. This is particularly valuable in packaging, printing, and assembly line applications where servo synchronization is critical.

Finally, for sites that require a programming connection during commissioning, the 5CASDL.0050-00 SDL programming cable or a standard USB-to-RS-232 adapter paired with Automation Studio 4.x provides full project download and diagnostic capability without additional hardware investment.

Retrofit Guidance FAQ

Q: Can I reuse existing field wiring when replacing the legacy panel PC with the 5PC810.SX05-00?
A: Yes. The 5PC810.SX05-00 uses the same 24 VDC power input and standard connector pinout as earlier Automation PC 810 variants. Field wiring to terminal blocks, I/O modules, and communication ports does not require modification in the majority of retrofit scenarios.

Q: Is my existing Automation Studio 3.x project compatible with the 5PC810.SX05-00?
A: The 5PC810.SX05-00 requires Automation Studio 4.x. B&R provides a project migration wizard within Automation Studio 4.x that converts AS3.x projects with minimal manual intervention. Function blocks and library calls should be reviewed post-migration for deprecated API compatibility.

Q: Will the 5PC810.SX05-00 fit in the same control cabinet cutout as my legacy unit?
A: The Automation PC 810 series maintains a consistent mechanical form factor across variants. In most installations, the 5PC810.SX05-00 is a direct physical replacement with no cabinet modification required. Verify the exact panel cutout dimensions against the product datasheet if your installation uses a custom enclosure.

Q: What communication protocols does the 5PC810.SX05-00 support natively?
A: The unit supports Gigabit Ethernet (Modbus TCP, EtherNet/IP, POWERLINK via software stack), RS-232/422/485 serial, and USB 3.0. Additional fieldbus protocols (PROFIBUS, CAN, DeviceNet) are supported via optional PCI interface modules installed in the unit’s expansion slots.

Q: How long does commissioning typically take for a panel PC swap?
A: For a like-for-like replacement within the Automation PC 810 family, experienced engineers typically complete hardware swap, project download, and functional verification within 4–8 hours of planned downtime. Cross-series migrations (e.g., from Automation PC 600) may require 1–2 additional days for project migration and I/O re-mapping.

Q: What if I need to replace a discontinued model that is no longer available from B&R directly?
A: TOPNLMS maintains stock of both current and discontinued B&R Automation PC components. If your exact legacy model is no longer available, our technical team can identify the closest compatible replacement within the Automation PC 810 series and provide a compatibility assessment before shipment.

Warranty Assurance

Every B&R 5PC810.SX05-00 unit supplied by TOPNLMS is covered by a 12-month warranty from the date of shipment. Prior to dispatch, each unit undergoes a multi-point functional inspection covering power-on self-test, communication interface verification, display output confirmation, and storage media integrity check. Units that do not pass inspection are not shipped.

In the event of a warranty claim, TOPNLMS provides a replacement unit or full refund within the warranty period, subject to inspection of the returned item. Our after-sales response target is 24 hours for initial fault assessment and 5 business days for replacement dispatch. Warranty coverage applies to manufacturing defects and component failures under normal operating conditions; it does not cover physical damage caused by incorrect installation or electrical overstress.

For procurement teams requiring documentation, TOPNLMS can provide a test report, packing list, and commercial invoice with each shipment. Export from Xiamen, China is supported via DHL Express, FedEx International Priority, and sea freight consolidation for bulk orders. Lead time for in-stock units is typically 3–7 business days to most international destinations.

To confirm stock availability, request a compatibility assessment, or place an order, contact our technical sales team directly.
