Allen-Bradley 1305-BA09A-HA2 Replacement for 1305 Series

Product Overview

Allen-Bradley 1305-BA09A-HA2 Replacement for 1305 Series: Seamless Transition & Legacy System Compatibility

The Allen-Bradley 1305-BA09A-HA2 is a Bulletin 1305 Series AC Variable Speed Drive designed for 3-phase induction motor control in industrial automation environments. As the 1305 Series approaches end-of-life and spare parts become increasingly scarce, many facilities running legacy control panels, MCC (Motor Control Center) lineups, and standalone drive enclosures are actively seeking a reliable, drop-in compatible replacement or upgrade path. This listing provides a tested, verified unit — either original surplus or functionally equivalent replacement — to support your retrofit, modernization, or emergency repair project with minimal disruption to production.

Whether your existing system is built around a Rockwell Automation / Allen-Bradley control architecture using a MicroLogix 1000, SLC 500, or PLC-5 controller communicating over DeviceNet or hardwired I/O, the 1305-BA09A-HA2 integrates directly into your existing wiring scheme. The drive accepts standard 3-phase AC input and delivers variable frequency output to the motor, maintaining the same terminal block layout and DIN rail or panel-mount footprint as the original 1305 Series units — a critical factor when retrofitting inside a constrained control cabinet.

Compatibility Comparison Table

Seamless Upgrade Solutions

A successful 1305-BA09A-HA2 migration rarely involves the drive alone. In most industrial retrofit scenarios, the surrounding system components must be evaluated and — where necessary — replaced or upgraded in parallel to ensure a stable, production-ready result.

For facilities running an SLC 500 or MicroLogix 1100 as the host controller, the existing ladder logic program typically uses analog output (AO) modules or DeviceNet messaging to command the drive speed reference. When swapping the 1305-BA09A-HA2, verify that the 1746-NO4I analog output module (for SLC 500 racks) or the equivalent MicroLogix AO channel is still within calibration range — a miscalibrated AO signal is a common cause of speed reference errors after a drive replacement.

If your control cabinet uses a 1305-DN DeviceNet option card installed in the original drive, confirm the node address and baud rate settings before removal. The DeviceNet network may also include a 1769-SDN Scanner Module (for CompactLogix systems) or a 1747-SDN Scanner (for SLC 500 racks) managing the network. These scanners store the drive’s EDS (Electronic Data Sheet) configuration, which must be updated or re-mapped if migrating to a PowerFlex 4M or PowerFlex 40 as a modern alternative.

Power quality at the drive input is another critical factor. Many legacy 1305 installations include a 1321-3R line reactor or an input EMI filter on the incoming 3-phase supply. These components protect the drive from voltage transients and reduce harmonic distortion on the supply bus. Inspect these components during the replacement — a failed or undersized line reactor is a frequent root cause of premature drive failure in retrofit projects.

On the output side, if the motor cable run exceeds 30 meters, consider whether a 1321-M output reactor is installed between the drive and motor. Long cable runs without output reactors can cause reflected wave voltage stress on motor windings, particularly with older motors not rated for inverter duty. This is especially relevant when upgrading from the 1305 to a higher-switching-frequency drive such as the PowerFlex 40.

For facilities that require local operator control, the original 1305 Series used a 1305-HIM Human Interface Module (remote keypad) for parameter access and speed reference. If the HIM is mounted on the cabinet door, verify cable compatibility with the replacement unit. In modernization projects, many engineers opt to replace the HIM with a PanelView Component C400 or a PanelView Plus 600 HMI terminal, which provides a more intuitive operator interface and supports remote diagnostics over EtherNet/IP.

Finally, for facilities transitioning to a fully networked architecture, the 1305-BA09A-HA2 replacement project is often the trigger for a broader migration to EtherNet/IP-capable drives such as the PowerFlex 525 (25B series), which supports integrated safety, embedded EtherNet/IP, and Studio 5000 / RSLogix 5000 Add-On Profile (AOP) integration — eliminating the need for a separate DeviceNet scanner and simplifying the overall network topology.

Retrofit Guidance FAQ

Q: Can I reuse the existing motor wiring when replacing the 1305-BA09A-HA2?
A: Yes, in most cases. The 1305-BA09A-HA2 uses standard U/V/W output terminals. As long as the replacement unit has the same output current rating (9A) and voltage class, the existing motor cable and terminal connections can be reused without modification. Always verify motor nameplate data against drive output specifications before energizing.

Q: Do I need to re-enter all drive parameters after replacement?
A: Yes. Drive parameters are stored in the unit’s non-volatile memory and are not transferable between physical units. Before removing the original drive, document all parameter settings using the keypad or DriveExplorer / DriveExecutive software. After installing the replacement, restore parameters manually or via software upload. Key parameters include motor nameplate data (voltage, current, frequency, speed), acceleration/deceleration ramps, and any application-specific tuning values.

Q: Is the 1305-BA09A-HA2 compatible with DeviceNet networks?
A: The base 1305-BA09A-HA2 supports hardwired analog and digital I/O control. DeviceNet connectivity requires the optional 1305-DN communication option card. If your existing installation uses DeviceNet, confirm whether the option card is present in the unit being replaced and whether a matching card is included with the replacement unit.

Q: What are the physical installation space requirements?
A: The 1305 Series drives are designed for panel mounting with specific clearance requirements above and below the unit for airflow. Refer to the 1305 Series User Manual (Rockwell Publication 1305-UM001) for exact dimensions and clearance specifications. When retrofitting into an existing cabinet, verify that the thermal management (ventilation slots, cooling fans) is adequate for the replacement unit’s heat dissipation rating.

Q: Can the 1305-BA09A-HA2 be replaced with a PowerFlex 4M or PowerFlex 40?
A: Yes, this is a common upgrade path. The PowerFlex 4M (22F series) and PowerFlex 40 (22B series) are the recommended modern replacements for the 1305 Series. However, this is not a direct drop-in swap — the mounting footprint, terminal layout, and parameter structure differ. A wiring adapter or terminal block reconfiguration is typically required, and the control program may need to be updated to reflect the new drive’s I/O mapping and communication profile.

Q: How do I handle the transition if the system is running 24/7 with minimal downtime windows?
A: Pre-stage the replacement unit with all parameters pre-loaded and tested on a bench setup before the maintenance window. Prepare a wiring diagram showing the terminal-for-terminal swap. Have the replacement unit, tools, and documentation ready before the shutdown. A well-prepared 1305-BA09A-HA2 swap can typically be completed within a 2–4 hour maintenance window, including functional testing.

Warranty Assurance

Every Allen-Bradley 1305-BA09A-HA2 unit shipped by TOPNLMS is covered by a 12-month warranty from the date of shipment. Prior to dispatch, each unit undergoes a functional inspection to verify power-up, parameter access, and basic drive operation. Units are shipped in protective packaging with anti-static precautions appropriate for electronic industrial equipment.

In the event of a warranty claim, TOPNLMS provides responsive after-sales support via email and phone. Replacement or repair arrangements are handled on a case-by-case basis, with the goal of minimizing your production downtime. Our team has direct experience with Allen-Bradley / Rockwell Automation product lines and can assist with technical questions related to installation, parameter configuration, and system integration during the warranty period.

For procurement teams, we can provide product documentation, test reports, and shipping records upon request to support your incoming inspection and asset management processes. Stock availability is confirmed at time of order, and lead times are communicated clearly before payment to avoid supply chain surprises.

For volume orders, OEM procurement, or project-based supply of multiple 1305 Series units or associated components, please contact our sales team directly to discuss pricing, lead time, and technical support arrangements.
