AI-Tek 70084-1713-111 Ruggedized Speed Sensor Module

Product Overview

AI-Tek 70084-1713-111 Ruggedized Magnetic Pickup Speed Sensor: Industrial Resilience for Harsh Environments

The AI-Tek 70084-1713-111 is a variable reluctance magnetic pickup speed sensor engineered for continuous, reliable operation in the most demanding industrial environments. Designed under AI-Tek’s proven 70084 Series platform, this sensor delivers precise rotational speed measurement where conventional sensors fail — in high-temperature furnace lines, high-vibration mining conveyors, dust-laden cement plants, and electromagnetically noisy power generation facilities. Whether you are maintaining a critical turbine control loop, protecting a high-speed compressor drive, or synchronizing a multi-axis rolling mill, the 70084-1713-111 provides the signal integrity your control system depends on.

Rugged Specifications Table

Comprehensive Protection Solutions

The AI-Tek 70084-1713-111 does not operate in isolation — it is a critical sensing node within a broader industrial control and protection architecture. In a typical heavy-industry control cabinet, this sensor feeds its speed signal directly into a Siemens S7-300 or S7-1500 PLC via a high-speed digital input module such as the 6ES7321 series I/O module, where the PLC logic monitors for overspeed, underspeed, or stall conditions in real time. In DCS-based plants, the signal is conditioned and routed to a Honeywell C300 controller or an ABB AC800M DCS module for process-level speed supervision.

For drive protection, the 70084-1713-111 is commonly paired with Siemens SINAMICS G120 or S120 variable frequency drives, providing encoder-free speed feedback that enables closed-loop vector control without the fragility of optical encoders in dusty or wet environments. In safety-critical applications — such as turbine overspeed protection or conveyor runaway prevention — the sensor output is wired to a Pilz PNOZ safety relay module or a Rockwell Allen-Bradley GuardLogix safety PLC, where the speed signal triggers a safe-state output if thresholds are exceeded.

Power supply stability for the associated control circuitry is typically ensured by a Phoenix Contact QUINT industrial power supply or a Siemens SITOP PSU8200, both of which provide the clean, regulated 24 VDC required by the PLC input cards and signal conditioning modules. Communication between the speed monitoring subsystem and the plant SCADA layer is handled via PROFIBUS DP or PROFINET communication modules, ensuring that speed data is available for historian logging, alarm management, and predictive maintenance analytics. Terminal connections within the control cabinet are made through Phoenix Contact or Weidmüller terminal blocks, providing reliable, vibration-resistant wiring termination that matches the ruggedness of the sensor itself.

Application in Critical Infrastructure

In oil and gas upstream and midstream facilities, the AI-Tek 70084-1713-111 is deployed on gas compressor trains, pump drives, and wellhead control systems where continuous speed monitoring is a safety-of-life requirement. The sensor’s passive design — requiring no external excitation power — makes it inherently safe for use in Zone 1 and Zone 2 hazardous areas when installed with appropriate IS (intrinsically safe) barriers or Zener barriers in the associated control panel.

In coal and metal mining operations, the 70084-1713-111 monitors conveyor belt drive motors, crusher drives, and hoist systems operating in environments with extreme dust loading, mechanical shock, and wide temperature swings. Its stainless steel threaded body resists corrosion from coal dust, mineral slurries, and cleaning agents, while the passive magnetic pickup principle ensures signal output even at very low shaft speeds — critical for detecting slow-roll conditions before a drive is brought up to full speed.

In thermal and hydroelectric power generation, the sensor is used on turbine shaft speed monitoring systems, boiler feed pump drives, and cooling water pump trains. Power plant operators rely on the 70084 series for its long service life and field-replaceable design — a failed sensor can be swapped out during a planned maintenance window without specialized tooling, minimizing unplanned downtime on generation assets. In water and wastewater treatment plants, the sensor monitors aerator drives, sludge pump motors, and blower units operating in high-humidity, chemically aggressive environments where electronic sensors with active components are prone to premature failure.

In steel and aluminum smelting facilities, the 70084-1713-111 withstands radiated heat from furnaces, electromagnetic interference from large induction heating systems, and the mechanical vibration of rolling mill drives — conditions that would rapidly degrade optical or Hall-effect sensors. Its ability to operate reliably at temperatures up to 150°C makes it suitable for installation close to hot process equipment without the need for thermal isolation standoffs.

Security & Quality FAQ

Q1: What does the 12-month warranty cover for the AI-Tek 70084-1713-111?
The 12-month warranty covers all manufacturing defects and functional failures under normal operating conditions from the date of shipment. If the unit fails to meet its specified output characteristics during this period, TOPNLMS will arrange replacement or refund. The warranty does not cover damage resulting from incorrect installation, overvoltage, or physical impact beyond the sensor’s rated mechanical limits.

Q2: How is each unit tested before shipment?
Every AI-Tek 70084-1713-111 unit in our inventory undergoes pre-shipment functional verification, including coil resistance measurement, output signal continuity check, and visual inspection of the threaded body, connector, and cable assembly. Units that do not pass inspection are quarantined and not shipped. A test report is available upon request for critical infrastructure procurement.

Q3: Is the 70084-1713-111 compatible with my existing PLC or DCS speed input card?
Yes — as a passive variable reluctance sensor, the 70084-1713-111 generates a self-powered sinusoidal AC signal that is compatible with virtually all PLC speed/frequency input modules and DCS tachometer input cards from Siemens, Rockwell, Honeywell, ABB, Yokogawa, and Schneider Electric. No signal conditioner is required for most standard applications. For very low-speed applications or long cable runs, a signal conditioner or frequency-to-voltage converter may be recommended.

Q4: Can TOPNLMS guarantee long-term supply and replacement support for this part?
Yes. TOPNLMS maintains stock of AI-Tek 70084 series sensors and actively sources replacement inventory to support long-lifecycle industrial installations. If the exact 70084-1713-111 configuration is unavailable, our technical team can identify functionally equivalent AI-Tek variants or cross-reference compatible third-party replacements with matching thread size, coil impedance, and connector configuration — ensuring your production line is never held up by a single obsolete part number.
