ABB 87TP01 Replacement Upgrade Solution for AC500 S500

Product Overview

ABB 87TP01 Replacement Upgrade Solution for AC500 S500: Seamless Transition from Legacy PROFIBUS Systems

The ABB 87TP01 is a PROFIBUS DP Coupler Module designed for the AC500 PLC platform, serving as the critical communication bridge between the AC500 CPU rack and distributed S500 I/O stations over PROFIBUS DP networks. As industrial facilities phase out aging PROFIBUS infrastructure or replace discontinued coupler modules, the 87TP01 stands as the direct drop-in solution — preserving existing wiring topology, DP slave addressing, and GSD-based configuration without requiring a full system redesign.

For plants currently operating legacy coupler variants or third-party PROFIBUS interface modules within the same S500 I/O bus architecture, migrating to the 87TP01 eliminates the need to re-engineer the fieldbus segment. The module slots directly into the S500 I/O bus rail, maintaining the same DIN-rail footprint and backplane connector pinout as predecessor coupler types. Field wiring to the PROFIBUS DP trunk — including the DB9 or terminal-based DP connector — remains unchanged, and the existing DP address set on the rotary switches transfers directly to the replacement unit.

Compatibility Comparison Table

Seamless Upgrade Solutions

A successful migration to the ABB 87TP01 rarely involves the coupler alone. In practice, field engineers replacing a failed or end-of-life PROFIBUS coupler within an AC500 S500 station will simultaneously audit the adjacent I/O modules on the same bus rail. Digital input modules such as the DI524 (16-channel 24 V DC) and digital output modules such as the DO524 are commonly found in the same S500 station and should be inspected for firmware currency and terminal block condition during the same maintenance window. Analog modules — including the AI523 (4-channel analog input, 0–20 mA / 4–20 mA) and AO523 (4-channel analog output) — share the same S500 backplane power rail and benefit from simultaneous verification of loop integrity.

On the PROFIBUS trunk itself, the network segment connecting the AC500 CPU rack to the 87TP01 slave station typically passes through a PROFIBUS repeater or optical link module where cable runs exceed 200 m or where electrical isolation is required between segments. Replacing the coupler is an ideal moment to verify that the DP termination resistors at both ends of the segment are correctly enabled — a common source of intermittent communication faults that are often misattributed to the coupler itself.

For facilities upgrading from an older AC500 CPU — such as a PM554 or PM564 — to a current-generation PM591 or PM592 as part of the same modernization project, the 87TP01 coupler remains fully compatible across the entire AC500 CPU family. The PROFIBUS DP master configuration stored in Automation Builder transfers without modification, and the GSD file for the 87TP01 slave station does not need to be re-imported. This means the CPU swap and coupler replacement can be executed independently, reducing the risk of a combined outage.

Where the control cabinet also houses an AC500 communication module — such as the CM572-DP (PROFIBUS DP master/slave) or the CM577-ETH (Ethernet/IP and Modbus TCP) — these modules continue to operate alongside the 87TP01 without configuration changes. Similarly, if the system includes an ABB CP600 or CP620 HMI panel connected to the AC500 CPU via Modbus RTU or Ethernet, the HMI tag database and screen logic are unaffected by the PROFIBUS coupler replacement. The TB521-ETH terminal base and associated power supply modules (PS501 or PS560) within the same cabinet also remain in service without modification.

For sites that require a spare 87TP01 to be held in inventory alongside other critical S500 spares — such as the DC532 (digital combination I/O), the AI531 (RTD/thermocouple input), or the CI590-CS31-HA (CS31 coupler for legacy field devices) — TOPNLMS maintains stock of all these modules and can fulfill multi-line purchase orders with consolidated shipping to minimize freight cost and customs clearance complexity.

Retrofit Guidance FAQ

Q: Can I replace the 87TP01 without downloading a new program to the AC500 CPU?
In most cases, yes. Because the 87TP01 retains the same GSD-defined I/O map as its predecessor, the CPU’s PROFIBUS DP master configuration does not change. Set the rotary address switches on the new module to match the original slave address, reconnect the DP cable, and power up. The CPU will re-establish communication automatically on the next bus scan cycle. A CPU download is only required if the original GSD configuration was modified or if the CPU firmware has been updated to a version that requires re-validation of the hardware configuration.

Q: Is the existing PROFIBUS DP wiring compatible with the 87TP01?
Yes. The 87TP01 uses a standard DB9 PROFIBUS DP connector. Existing shielded twisted-pair PROFIBUS cable (Type A, impedance 135–165 Ω) connects directly. Verify that the cable shield is grounded at one end only and that the bus termination at the physical end of the segment is active. No re-wiring of the DP trunk is required.

Q: What happens to the S500 I/O modules downstream of the coupler during replacement?
The S500 I/O modules (DI, DO, AI, AO) mounted on the same bus rail lose communication with the CPU during the coupler swap. Outputs will de-energize (fail-safe state) and inputs will freeze at last value in the CPU’s process image. Plan the replacement during a scheduled maintenance window or coordinate with the process control team to place the affected control loops in manual mode before proceeding.

Q: How much cabinet space does the 87TP01 require?
The 87TP01 occupies a single S500 module slot on the DIN rail bus rail — identical to the module it replaces. No additional cabinet space, cable duct modification, or DIN rail extension is required. The module depth and height conform to the standard S500 form factor.

Q: Can the 87TP01 operate on a PROFIBUS network with mixed baud rates or multiple masters?
The 87TP01 auto-detects the baud rate set by the PROFIBUS DP master (AC500 CPU or CM572-DP communication module) and does not require manual baud rate configuration. Multi-master PROFIBUS networks are supported provided the 87TP01 is configured as a DP slave in the GSD configuration of each master that needs to access its I/O data.

Q: What is the lead time and shipping arrangement?
In-stock units ship within 1–3 business days from Xiamen, China via DHL Express or FedEx International Priority. Typical transit time to Europe is 3–5 business days; to North America, 4–6 business days. A commercial invoice, packing list, and HS code declaration are provided with every shipment to facilitate customs clearance.

Warranty Assurance

Every ABB 87TP01 PROFIBUS DP Coupler Module supplied by TOPNLMS is covered by a 12-Month Warranty from the date of shipment. Prior to dispatch, each unit undergoes a pre-shipment functional inspection that verifies power-up behavior, LED status indication, and PROFIBUS DP communication initialization using a calibrated test bench. Units that do not pass inspection are quarantined and not shipped.

In the event of a warranty claim, TOPNLMS will arrange a replacement unit or issue a full refund — at the buyer’s election — within 5 business days of receiving the returned defective module. Return shipping costs for confirmed warranty defects are covered by TOPNLMS. Warranty claims must be submitted to [email protected] with the order reference number, a description of the fault, and photographic evidence of the module and its installation environment.

TOPNLMS does not supply counterfeit, refurbished-as-new, or grey-market modules. All units are sourced through verified supply channels and are accompanied by original manufacturer packaging where available. Buyers requiring third-party inspection, material traceability documentation, or certificate of conformance should contact our sales team prior to order placement.
